Ortial ON-750-128 512GB PCIe 3.0 TLC NVMe SSD (ORTIAL ON-750 512GB M.2 2280 NVME SSD)


Brand: Ortial
Product name: ON-750-128 512GB PCIe 3.0 TLC NVMe SSD
Product code: ON-750-512
EAN/UPC code: 5060634256131
  • 512 GB M.2 PCI Express 3.0
  • Read speed: 2044 MB/s 170000 IOPS
  • Write speed: 1685 MB/s 150000 IOPS
  • TLC NVMe

In stock

SKU: B44852546 Category: Tag:


The ON-750 is designed to deliver optimal performance and increased storage density, accelerated with the latest PCIe technology. Offering enhanced reliability and endurance for read-intensive workloads.
NVMe is a key component in any datacentre or desktop environment, instantly upgrading servers and high-spec desktop and laptops.


SSD form factor
The size of the solid-state drive, given in inches
SSD capacity
The Solid State Drive’s data storage capacity.
512 GB
Interface ports to connect pieces of equipment. USB (Universal Serial Bus) has become the most popular wired interface to connect peripherals. USB 2.0 supports speeds up to 480 Mbit/s (USB 1: 12 Mbit/s). The interface FireWire is also known as the IEEE 1394 standard. Enhanced IDE (EIDE)is sometimes referred to as Fast ATA, Fast IDE or ATA-2.
PCI Express 3.0
Memory type
Type of memory in the device e.g. DDR3, SRAM (Static RAM).
NVM Express (NVMe) or Non-Volatile Memory Host Controller Interface Specification (NVMHCIS) is an open logical device interface specification for accessing non-volatile storage media attached via a PCI Express (PCIe) bus. NVM Express, as a logical device interface, has been designed to capitalize on the low latency and internal parallelism of solid-state storage devices.
Component for
What this product is used as a part of (component for).
Read speed
The speed at which a device can read data.
2044 MB/s
Write speed
The speed at which a device can write data.
1685 MB/s
Random read (4KB)
170000 IOPS
Random write (4KB)
150000 IOPS
Mean time between failures (MTBF)
Statistical model used to indicate product/mechanism reliability; expressed in hours and percentage of duty cycle. This number (in hours) does not indicate the mean time before failure for a single unit/mechanism.
1000000 h
Operational conditions
Operating temperature (T-T)
The minimum and maximum temperatures at which the product can be safely operated.
0 – 70 °C
Storage temperature (T-T)
The minimum and maximum temperatures at which the product can be safely stored.
-40 – 85 °C
Operating relative humidity (H-H)
5 – 98%
Storage relative humidity (H-H)
5 – 98%
Weight & dimensions
The measurement or extent of something from side to side.
22 mm
The distance from the front to the back of something.
80 mm
The measurement of the product from head to foot or from base to top.
2.2 mm
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
7 g
Packaging data
Quick start guide
Instructions, either online, as a computer program or in paper form, to allow you to set up and start using the product quickly.
