Asrock RX7900 XT Phantom Gaming 20G OC, PCIe4, 20GB DDR6, HDMI, 3 DP, 2450MHz Clock, RGB, Overclocked
£802.99
Description
Specification
- Chipset Manufacturer: AMD
- Interface: PCI Express 4.0
- Graphics Chipset: AMD RX 7900 XT
- Memory Size: 20GB
- Memory Type: DDR6
- Memory Interface: 320-bit
- Core Clock: Boost Clock: Up to 2450 MHz
Game Clock: 2075 MHz - Memory Clock: 20 Gbps
- CUDA Cores / Stream Processors: 5376 Stream Processors
- Outputs: 1 x HDMI
3 x DisplayPort - HDCP Support: Yes
- Resolution: Digital Max Resolution: 7680 x 4320
- DirectX Support: DirectX 12 Ultimate
- Max Display Support: 4
- Cooling: Phantom Gaming 3X Cooling System
Striped Ring Fan
Reinforced Metal Frame
Stylish Metal Backplate
0dB Silent Cooling - PSU Requirements: 750W or greater recommended
- Connectors Required: 2 x 8-pin PCIe Power
- Additional Features: See Overview
- Dimensions: 330 x 140 x 57.6 mm
- Slot Size: 2.8 Slot
- Accessories: 1 x Quick Installation Guide
- Package Type: Retail
- #Hide#Lighting Effects: Yes
- #Hide#HDMI: Yes (HDMI)
- #Hide#DisplayPort: Yes (DisplayPort)
- Package Weight: 2.3000 kg
- Warranty: 2 Year Replacement Warranty
In stock
Description
RX 7900 XT Phantom Gaming 20GB OC
- Boost Clock: Up to 2450MHz / 20Gbps
- Game Clock: 2075MHz / 20Gbps
- AMD Radeon™ RX 7900 XT GPU
- 20GB GDDR6 on 320-Bit Memory Bus
- 84 AMD RDNA™ 3 Compute Units (With Rt+Ai Accelerators)
- 80MB AMD Infinity Cache™ Technology
- PCI® Express 4.0 Support
- 2 x 8-pin Power Connectors
- 3 x DisplayPort™ 2.1 / 1 x HDMI™ 2.1
- Polychrome SYNC
- Phantom Gaming 3X Cooling System
- Striped Ring Fan
- Reinforced Metal Frame
- Stylish Metal Backplate
- 0dB Silent Cooling
- Super Alloy Graphics Card
Reverse Spin
The center fan spins reversely to lower turbulence and enhance air dispersion through the heatsink.
Phantom Gaming 3X Cooling System
For Cool And Silent.
Crafted for the best balance between the thermal efficiency and silence by all the details.
Striped Ring Fan
Designed For Enhanced Airflow
ASRock’s all new Striped Ring Fan get more lateral intake and to provide better airflow through the cooling array.
Air Deflecting Fin
Guide Airflow To Go Through Regularly & Quickly.
Guide the airflow to go more regularly and quickly to enhance the cooling efficiency by the V-shaped cutting fins and the V-shaped air vents.
Ultra-Fit Heatpipe
Consolidated To Maximize The Contact.
The heatpipes are consolidated to maximize the contact among each others and also the GPU baseplate for the optimized heat dissipation.
Nickel-Plated Copper Base
Maximize GPU Contact Area.
With premium copper base heatsink design, the direct contact area to the GPU would be maximized to improve thermal transfer effectively.
High-Density Metal Welding
Improve Heat Dissipation.
Effectively isolate all coverage of the gap between pipe and stacked fins, hence improve heat dissipation effectively.
Nano Thermal Paste
Perfect Thermal Teamwork.
Eliminate the gaps in the contact area to maximize heat transfer and thermal efficiency.
Premium Thermal Pad
Better Heat Transfer.
The premium thermal pad helps to transfer the heat of the components to the heatsink, improving heat dissipation.
Precise Screw Torque
Optimized Mounting Pressure.
ASRock adopts precise screw torque when assembling its graphics cards to optimize the cooler mounting pressure to improve thermal efficiency while avoiding damage to GPU die.
0dB Silent Cooling
Spin For Cooling, Stop For Silence.
The fan spins when the temperature goes high for the optimal cooling, and stops when the temperature goes low for the complete silence.
Polychrome SYNC
Create Your Own Unique Colorful Light Effects.
With the integrated ARGB LEDs, you can create your own unique colorful light effects which can also be switched on and off. It can also be synchronized with your ASRock motherboards that support Polychrome SYNC.
LED On/Off Switch
On Or Off? Switch As You Want.
You can switch not only the built-in ARGB LEDs but also the ARGB LEDs equipping with the connected strips/devices at once.
Reinforced Metal Frame
Reinforced Metal Frame
Enhances the structure to prevent the PCB from being bent.
Stylish Metal Backplate
Solid, Fancy, Cool.
Designed to avoid PCB bending. The fancy outlook makes the graphic card more legendary in visual. It also helps to enhance cooling with the premium thermal pads equipped backside.
Japanese SP-Cap
With a high conductive polymer as the electrolyte, it has a lower equivalent series resistance (ESR) to provide outstanding electrical characteristics. In addition to that, it also has excellence in product operational life, reliability and heat resistance.
SPS (Smart Power Stage)
Dr.MOS design features the latest SPS (Smart Power Stage) technology. It’s optimized for monitoring current and temperature of each phase, thus delivering smoother and neater power to the GPU with enhanced performance and OC capability.
Premium 100A Power Choke
Compared to traditional chokes, ASRock’s premium 100A power chokes effectively make the saturation current up to three times better, thus providing enhanced and improved Vcore voltage to the graphics card.
2oz Copper PCB
Using only carefully selected copper materials for PCB layers, 2oz Copper PCB delivers lower temperature and higher energy efficiency for overclocking.
Matte Black PCB
Matte Black PCB
A new mysterious matte black and copper color scheme to match the prestigious components on ASRock's high-end graphics card.
High Density Glass Fabric PCB
High Density Glass Fabric PCB design that reduces the gaps between the PCB layers to protect the graphics card against electrical shorts caused by humidity.
ASRock Tweak 2.0
Pro And Easy-To-Use Tuning Utility.
Provides the smart fan speed control and instant performance tweaking.
8K Resolution Support
Not only can it handles 4K graphics but also supports the next generation 8K video output for the ultimate visual experience.
PCI® Express 4.0 Support
This graphics card features PCI® Express 4.0 support, with a throughput of 16 GT/s and enables two times the bandwidth compared to PCI® Express 3.0. Get ready for the next generation of PC gaming.
Additional information
Weight | 2.3 kg |
---|---|
Brand | Asrock |
MPN | 90-GA3XZZ-00UANF |
