Asus PRIME H610M-K D4 ARGB, Intel H610, 1700, Micro ATX, 2 DDR4, HDMI, PCIe4, 1x M.2

Description

Specification

• Motherboard Type: Desktop
• Form Factor: Micro ATX
• Socket: Intel 1700
• Chipset: Intel H610
• #Hide#DDR Type: DDR4
• CPU Support: Click here for CPU support
• RAM Technology: “DDR4 (Dual Channel)
  Non-ECC, Un-buffered Memory
  Supports Intel Extreme Memory Profile (XMP)”
• RAM Slots: 2 x DIMM
• RAM Speeds: Up to 3200 MHz
• Maximum Memory: 64GB
• Graphics: Integrated Graphics
  Graphics specifications may vary between CPU types
• Graphics Ports: 1 x HDMI
• PCI/PCI Express: 1 x PCIe 4.0 x16 slot (supports x16 mode)
  1 x PCIe 3.0 x1
• Storage: 4 x SATA III
  1 x M.2 (2242/2260/2280) – PCIe 3.0 x4
• Wireless: –
• LAN: GB LAN
• Audio: Realtek 7.1 Surround Sound High Definition Audio CODEC
• USB Ports Supported: Rear:
  2 x USB 5Gbps Type-A
  4 x USB 2.0

  Front:
  2 x USB 5Gbps
  1 x USB 2.0

• Back Panel I/O Ports: 2 x USB 5Gbps Type-A
  4 x USB 2.0
  1 x HDMI
  1 x Realtek 1Gb Ethernet
  3 x Audio jacks
  1 x PS/2 keyboard/mouse combo
• Internal I/O Connectors: 1 x 4-pin CPU Fan
  1 x 4-pin Chassis Fan
  1 x 24-pin Main
  1 x 8-pin +12V
  1 x M.2 (Key M)
  4 x SATA 6Gb/s
  1 x USB 5Gbps
  1 x USB 2.0
  2 x Addressable Gen2
  1 x Clear CMOS
  1 x COM Port
  1 x Front Panel Audio
• .: 1 x S/PDIF Out
  1 x Speaker
  1 x SPI TPM (14-1 pin)
  1 x 10-1 pin System Panel
• Accessories: 2 x SATA 6Gb/s cables
  1 x I/O shield
  1 x M.2 anchor
  1 x Quick start guide
• Additional Features: See Overview
• Package Type: Retail
• Package Weight: 1.0000 kg
• Warranty: 3 Years
• #Hide#M.2 Slot(s): Yes (M.2)
• #Hide#No. LAN Ports: 1 x LAN
• #Hide#Max LAN Speed: GB LAN
