Asus PROART B660-CREATOR D4, Intel B660, 1700, ATX, 4 DDR4, HDMI, DP, 2.5GB LAN, PCIe5, 3x M.2, Creator Hub

Description

Specification

• Motherboard Type: Desktop
• Form Factor: ATX
• Socket: Intel 1700
• Chipset: Intel B660
• #Hide#DDR Type: DDR4
• CPU Support: Click here for CPU support
• RAM Technology: DDR4 (Dual Channel)
• RAM Slots: 4 x DIMM
• RAM Speeds: Up to 5333(OC)
• Maximum Memory: 128GB
• Graphics: Integrated Graphics*

  *Graphics specifications may vary between CPU types

• Graphics Ports: 1 x HDMI
  1 x USB 3.2 Gen2 Type-C supports DisplayPort output
  1 x DisplayPort (Input only)
• PCI/PCI Express: 1 x PCIe 5.0 x16
  1 x PCIe 3.0 x16
  1 x PCIe 3.0 x1
• Storage: 4 x SATA III
  1 x M.2 (2242/2260/2280/22110 ) – PCIe
  1 x M.2 (2242/2260/2280) – PCIe
  1 x M.2 (2242/2260/2280/22110) – PCIe
• RAID: Intel Rapid Storage Technology supports SATA RAID 0/1/5/10.
• Wireless: –
• LAN: 2.5GB LAN & GB LAN
• Audio: Realtek 7.1 Surround Sound High Definition Audio CODEC
• USB Ports Supported: “1 x USB 3.2 Gen2 Type-C (at back)
  6 x USB 3.2 Gen1 Type-A (4 at back, 2 at mid-board)
  10 x USB 2.0 (6 at back, 4 at mid-board)
  1 x USB 3.2 Gen2x2 Type-C front connector w/ 60W PD/QC4.0″
• Back Panel I/O Ports: 1 x DisplayPort (Input only)
  1 x HDMI
  1 x Realtek 2.5Gb Ethernet
  1 x Intel 1Gb Ethernet
  5 x Audio jacks
  1 x Optical S/PDIF out
  4 x USB 2.0
  4 x USB 3.2 Gen1 Type-A
  1 x USB Type-C supports USB 3.2 Gen2 & DisplayPort output
• Internal I/O Connectors: 1 x 4-pin CPU Fan
  1 x 4-pin CPU OPT Fan
  1 x 4-pin AIO Pump
  4 x 4-pin Chassis Fan
  1 x 24-pin Main
  1 x 8-pin +12V
  1 x 4-pin +12V
  3 x M.2 (Key M)
  4 x SATA 6Gb/s
  1 x USB 3.2 Gen1 Type-A
  2 x USB 2.0
  1 x USB 3.2 Gen2x2 (supports USB Type-C w/ 60W PD/QC4.0)
• Accessories: 1 x DisplayPort cable
  2 x SATA 6Gb/s cables
  3 x M.2 Rubber Packages
  1 x Q-connector
  1 x Support DVD
  1 x ACC Express Activation Key Card
  1 x User guide
• Additional Features: See Overview
• Package Type: Retail
• Package Weight: 2.1000 kg
• Warranty: 3 Years
• #Hide#M.2 Slot(s): Yes (M.2)
• #Hide#No. LAN Ports: 2 x LAN
• #Hide#Max LAN Speed: 2.5GB LAN
