Asus TUF GAMING B550-PLUS, AMD B550, AM4, ATX, 4 DDR4, HDMI, DP, XFire, 2.5GB LAN, PCIe4, RGB Lighting, M.2

Asus TUF GAMING B550-PLUS, AMD B550, AM4, ATX, 4 DDR4, HDMI, DP, XFire, 2.5GB LAN, PCIe4, RGB Lighting, M.2

£184.99

Description

Specification

  • Motherboard Type: Desktop
  • Form Factor: ATX
  • Socket: AMD AM4
  • Chipset: AMD B550
  • #Hide#DDR Type: DDR4
  • CPU Support: Click here for CPU support

    *Note: not compatible with Ryzen 5 3400G & Ryzen 3 3200G CPUs

  • RAM Technology: DDR4 (Dual Channel)
  • RAM Slots: 4 x DIMM
  • RAM Speeds: 3rd Gen AMD Ryzen CPUs:
    4600(O.C)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3333(O.C.)/3200/3000/2800/2666/2400/2133 MHz

    Next Gen AMD Ryzen PRO CPUs:
    4800(O.C.)/4600(O.C)/4466(O.C.)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3333(O.C.)/3200/3000/2800/2666/2400/2133 MHz

  • Maximum Memory: 128GB
  • Graphics: Integrated Graphics Processor*

    Graphics specifications may vary between CPU types

  • Graphics Ports: 1 x HDMI
    1 x DisplayPort
  • Multi-GPU Support: Supports AMD 2-Way CrossFireX Technology
  • PCI/PCI Express: 1 x PCIe 4.0 x16 (x16 mode)
    1 x PCIe 3.0 x16 (x4 mode)
    3 x PCIe 3.0 x1
  • Storage: 6 x SATA III
    2 x M.2 (2242/2260/2280/22110) – SATA & PCIe
  • RAID: “RAID 0, 1, 10”
  • LAN: 2.5GB LAN
  • Audio: Realtek ALC S1200A 7.1 Surround Sound High Definition Audio CODEC
  • USB Ports Supported: “2 x USB 3.2 Gen2 (1 Type-A & 1 Type-C at back)
    6 x USB 3.2 Gen1 (4 at back, 2 at mid-board)
    6 x USB 2.0 (2 at back, 4 at mid-board)”
  • Back Panel I/O Ports: 1 x DisplayPort
    1 x HDMI
    1 x LAN (2.5G)
    2 x USB 3.2 Gen2 (Type-A & Type-C)
    4 x USB 3.2 Gen1
    2 x USB 2.0
    1 x Optical S/PDIF out
    5 x Audio jacks
    1 x BIOS FlashBack Button
  • Internal I/O Connectors: 1 x CPU Fan
    1 x CPU OPT Fan
    3 x Chassis Fan
    1 x AIO_PUMP
    2 x Aura RGB Strip
    1 x Addressable Gen2
    1 x USB 3.2 Gen1
    2 x USB 2.0
    2 x M.2 Socket 3
    1 x M.2 with E key for Wi-Fi module
    1 x SPI TPM
    6 x SATA 6Gb/s
  • .: 1 x 24-pin EATX
    1 x 8-pin EATX 12V
    1 x Front audio
    1 x Thermal sensor
    1 x Clear CMOS jumper
    1 x System panel
    1 x COM port
  • Accessories: I/O Shield
    2 x SATA 6Gb/s cables
    1 x TUF Gaming Sticker
    1 x TUF Certification cards
    1 x M.2 SSD screw package
    1 x M.2 Rubber Package
  • Additional Features: See Overview
  • Package Type: Retail
  • Package Weight: 1.4100 kg
  • Warranty: 3 Years
  • #Hide#M.2 Slot(s): Yes (M.2)
  • #Hide#No. LAN Ports: 1 x LAN
  • #Hide#Max LAN Speed: 2.5GB LAN
  • #Hide#RGB Lighting: Out of the box RGB lighting

In stock

EAN: 4718017749435 SKU: 90MB14G0-M0EAY0 Category:

Description

AMD B550 (Ryzen AM4) ATX gaming motherboard with PCIe 4.0, dual M.2, 10 DrMOS power stages, 2.5 Gb Ethernet, HDMI, DisplayPort, SATA 6 Gbps, USB 3.2 Gen 2 Type-A and Type-C, and Aura Sync RGB lighting support

  • AMD AM4 socket: Ready for 3rd Gen AMD Ryzen™ processors
  • Enhanced power solution: 8+2 DrMOS power stages, ProCool sockets, military-grade TUF components, and Digi+ VRM for maximum durability
  • Comprehensive cooling: VRM heatsink, PCH fanless heatsink, M.2 heatsink, hybrid fan headers and Fan Xpert 4 utility
  • Next-gen connectivity: PCIe 4.0 M.2, USB 3.2 Gen 2 Type-A and Type-C support
  • Made for online gaming: 2.5 Gb Ethernet, M.2 slot (Key E) for Wi-Fi module, TUF LANGuard, and Turbo LAN technology
  • Realtek S1200A codec: Pristine audio quality with unprecedented 108 dB signal-to-noise ratio for stereo line out and 103 dB SNR for line in
  • AI noise-canceling microphone: provides crystal-clear in-game voice communication



Durable. Stable. Reliable.

TUF Gaming B550M-Plus distills essential elements of the latest AMD platform and combines them with game-ready features and proven durability. Engineered with military-grade components, an upgraded power solution and a comprehensive set of cooling options, this motherboard delivers rock-solid performance with unwavering gaming stability.

When you build with a TUF Gaming motherboard, you also benefit from the TUF Gaming Alliance – an ASUS collaboration with trusted industry partners that ensures easier building, best compatibility, and complementary aesthetics from components to case.





Rock-Solid Peformance

With upgraded power delivery and comprehensive cooling options to fuel the latest AMD Ryzen CPUs, plus support for faster memory and storage, TUF Gaming B550M-Plus is the perfect foundation for your next high-core-count battle rig.





Easy PC DIY

TUF Gaming motherboards are designed to be easy to set up and configure just the way you want – even for first-time builders. The TUF Gaming Alliance ecosystem makes selecting compatible parts easy, while Armoury Crate software offers full control of system settings via a single dashboard. TUF Gaming motherboards give you everything you need to build your dream gaming rig without adding complexity.





Build with Confidence

TUF Gaming Alliance is a collaboration between ASUS and trusted PC-component brands to ensure compatibility with a wide range of parts, such as PC cases, power supplies, CPU coolers, memory kits and more. With more partnerships and components being added regularly, the TUF Gaming Alliance will continue to grow even stronger.





Immersive Gaming

TUF Gaming B550M-Plus provides a complete, high-performance gaming package with a long list of features to improve your experience, including ultrafast networking for smoother online gameplay, pristine audio with positional cues for FPS gaming, and onboard RGB lighting that syncs with attached accessories to help you create a personalized gaming atmosphere.





Exclusive 2.5 Gigabit Ethernet

2.5G on-board Ethernet kicks your LAN connection up a notch with an up to 2.5X bandwidth improvement. Using your existing LAN cable, you can take advantage this networking upgrade to experience smoother, lag-free gaming, immediately stream high-resolution videos and enjoy faster file transfers.





M.2 Slot (Key E) for Wi-Fi Module

TUF Gaming B550-Plus comes along with an M.2 (Key E) slot which gives you the flexibility to upgrade your networking solution by installing an M.2 Wi-Fi/Bluetooth module.





Turbo LAN

Network-Optimization Software for Customizable Packet Prioritization
Turbo LAN is a network-optimization software for customizable packet prioritization. With cFosSpeed traffic-shaping technology, it allows you to configure application priority via an intuitive interface, and reduces network lag.

Additional information

Weight 1.41 kg
Brand

Asus
MPN

90MB14G0-M0EAY0
