DeepCool PX1200G 1200W PSU, ATX 3.0, PCIe 5.0 12VHPWR, 135mm FDB Fan, 80 PLUS Gold

Description

PAST, PRESENT, AND FUTURE
With the ability to provide three times the total GPU and twice the total system power for 0.1 ms, power spikes will never be an issue. The PX1200G will provide stable and consistent power for legacy and next-generation PCs for the foreseeable future.

PREMIUM QUALITY
Solid and reliable power is provided through the use of full Japanese 105C capacitors. Due to the high quality of the PSU build, the PX1200G will operate at altitudes up to 5000 meters above sea level.

RELIABLE STABILITY
Through the use of a dual main capacitor topology, the PX1200G can keep the hold-up time to = 16ms under full load.

PCI-E 5.0 POWER PERFECTED
Equipped with the new PCI-e Gen 5.0 12VHPWR cable, the PX-G provides up to 600W for power hungry GPUS.

Specifications

Type
ATX12V V3.0

Product Dimensions
150 x 160 x 86mm (W x L x H)

Efficiency certification
80Plus GOLD/Cybenetics_GOLD

Fan Size
135mm Fan

Bearing
FDB (Fluid Dynamic Bearing)

Topology
Active PFC + Half Bridge SRC LLC + DC to DC

Capacitors
Full Japan Electrolytic Capacitors

Power Good Signal
100-150ms

Hold Up Time
=16ms

Efficiency
=90% Under Typical Load (50% Loading)

Protection
OPP/OVP/SCP/OTP/OCP/UVP

Operation Temperature
0 – 40?

Regulatory
CE/FCC/CCC/TUV-RH/RCM/EAC/CAN ICES-003(B)/NMB-003(B)/UKCA/BIS;

Connectors
1 x 16-pin PCIe
2 x 4+4-pin CPU +12V (EPS)
4 x 4-pin Molex
3 x 6+2-pin PCIe
8 x SATA

Erp Regulation
ErP 2014

MTBF
100,000 Hours
