TP-LINK (EAP653) AX3000 Dual Band Ceiling Mount Wi-Fi 6 Access Point, PoE+, Omada Mesh, Ultra Slim Design
£121.99
- Type: Access Point
- Speed:
- PoE: Yes
In stock
Description
AX3000 Ceiling Mount WiFi 6 Access Point
Key Features
Ultra-Fast WiFi 6 Speeds: Simultaneous 574 Mbps on 2.4 GHz and 2402 Mbps on 5 GHz totals 2976 Mbps WiFi speeds.
High-Efficiency WiFi 6: More connected devices can enjoy faster speeds.
Centralized Cloud Management: Omada SDN integration manages the whole network locally or from the cloud via web UI or Omada app.
160 MHz Channel: Double the data at peak transmission times on a single stream with HE160.
Seamless Roaming: Video streams and voice calls are unaffected as users move between locations.
Omada Mesh: Enables wireless connectivity between access points for extended range and flexible deployment.
PoE+ Powered: Supports both 802.3at PoE+ and DC (DC adapter sold separately) power supply for flexible installations.
Ultra-Slim Design: F160 mm x 33.6 mm elegant design brings more agility
Designed for Business Environments Requiring High-Performance WiFi
Hospitality – High-quality and full coverage Guest WiFi
Education – High-security WiFi to connect more devices
Shopping Mall – Seamless marketing WiFi coverage to boost business
Office – Stable, seamless, and high-security WiFi coverage
Meeting Room – Faster streaming, downloading, video conferencing, and more
Power up Your Business with New-Era Business WiFi 6
WiFi 6 brings faster speeds, lower lag, less interference, and higher capacity.
Lightning-Fast AX3000 WiFi 6 Speeds
New-era business WiFi 6 with speeds up to 2976 Mbps brings more than twice the speed of WiFi 5.โ Every application feels more fluid with drastically improved WiFi speeds.
Seamless Integration into Omada SDN
The Omada Software Defined Networking (SDN) platform integrates network devices, including access points, switches, and routers. It provides 100% centralized cloud management and creates a highly scalable network controlled from a single interface.
Auto Channel Selection and Power Adjustment to Optimize Overall Performance
Provides powerful wireless performance while significantly reducing WiFi interference by automatically adjusting the channel settings and transmission power levels of neighboring APs in the same network.
Easy Pairing, Less Wiring
With Mesh technology, Omada EAPs save you from extra wires by wirelessly extending your WiFi signal further and more flexibly to hard-to-wire areas.
Optimized Network Performance
Intelligent self-organization optimizes the best path between EAPs while self-healing ensures you stay online even when one AP is disrupted.
Always Stay Smooth with Fast Roaming
Ensures customers to enjoy uninterrupted streaming when moving around by switching clients automatically to the access points with the optimal signal.
Ultra-Slim Design Brings More Agility
Exceptional performance with compact design ensures simple WiFi installation while saving space. The elegant appearance makes EAP653 perfectly blend into any modern office, hotel, classroom, or cafรฉ.
Easy to Mount with Refined Industrial Design
1
Push up
2
Rotate to lock
Ceiling / Wall / Junction Box Mounting (Kits included)
Specifications
HARDWARE FEATURES
Interface
1 x Gigabit Ethernet (RJ-45) Port (supports IEEE802.3at PoE)
Button
Reset
Power Supply
โข 802.3at PoE
โข 12V DC
(EU Version: 12 V / 1.0 A DC. US Version: 12 V / 1.5 A DC).
Note: DC adapter is not included in the package, and is sold separately.
Power Consumption
โข EU: 13.5 W
โข US: 14.7 W
Dimensions ( W x D x H )
6.3 x 6.3 x 1.3 in (160 x 160 x 33.6 mm)
Antenna Type
Internal Omni
โข 2.4 GHz: 2 x 4 dBi
โข 5 GHz: 2 x 5 dBi
Mounting
โข Ceiling /Wall Mounting (Kits included)
โข Junction Box Mounting
WIRELESS FEATURES
Wireless Standards
IEEE 802.11ax/ac/n/g/b/a
Frequency
2.4 GHz and 5 GHz
Signal Rate
โข 5 GHz: Up to 2402 Mbps
โข 2.4 GHz: Up to 574 Mbps
Wireless Functions
โข 1024-QAM
โข 4 x Longer OFDM Symbol
โข OFDMA
โข Multiple SSIDs (Up to 16 SSIDs, 8 for each band)
โข Enable/Disable Wireless Radio
โข Automatic Channel Assignment
โข Transmit Power Control (Adjust Transmit Power on dBm)
โข QoS(WMM)
โข MU-MIMO
โข HE160 (160 MHz Bandwidth)
โข Seamless Roaming
โข Omada Mesh
โข Band Steering
โข Load Balance
โข Airtime Fairness
โข Beamforming
โข Rate Limit
โข Reboot Schedule
โข Wireless Schedule
โข Wireless Statistics based on SSID/AP/Client
Wireless Security
โข Captive Portal Authentication
โข Access Control
โข Wireless Mac Address Filtering
โข Wireless Isolation Between Clients
โข SSID to VLAN Mapping
โข Rogue AP Detection
โข 802.1X Support
โข WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
Transmission Power
โข CE
<20 dBm(2.4 GHz, EIRP)
<23 dBm(5 GHz, Band1 & Band2, EIRP)
<27 dBm(5 GHz, Band3, EIRP)
โข FCC
<22 dBm (2.4 GHz)
<22 dBm (5 GHz)
MANAGEMENT
Yes
Centralized Management
โข Omada Hardware Controller (OC300)
โข Omada Hardware Controller (OC200)
โข Omada Software Controller
โข Omada Cloud-Based Controller
Cloud Access
Yes (Through OC300, OC200, Omada Software Controller, or Omada Cloud-Based Controller)
Email Alerts
Yes
LED ON/OFF Control
Yes
Management MAC Access Control
Yes
SNMP
v1, v2c, v3
System Logging Local/Remote Syslog
Local/Remote Syslog
SSH
Yes
Web-based Management
HTTP/HTTPS
L3 ManagementYes
Multi-site Management
Yes
Management VLAN
Yes
Zero-Touch Provisioning
Yes. Requiring the use of Omada Cloud-Based Controller.
OTHERS
Certification
CE, FCC, RoHS
Package Contents
โข EAP653
โข Ceiling/Wall Mounting Kits
โข Installation Guide
Note: DC adapter is not included in the package, and is sold separately.
System Requirements
Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows 11, Linux
Environment
โข Operating Temperature: 0โ40 ? (32โ104 ?)
โข Storage Temperature: -40โ70 ? (-40โ158 ?)
โข Operating Humidity: 10โ90% RH non-condensing
โข Storage Humidity: 5โ90% RH non-condensing
Additional information
Weight | 0.71 kg |
---|---|
Brand | TP-LINK |
MPN | EAP653 |
