TP-LINK (TL-SG1218MP) 18-Port Gigabit Unmanaged PoE+ Rackmount Switch, 16-Port PoE+, 2 SFP Ports

TP-LINK (TL-SG1218MP) 18-Port Gigabit Unmanaged PoE+ Rackmount Switch, 16-Port PoE+, 2 SFP Ports

£181.99

Description

Specification

  • Rackmountable: Yes
  • Managed: No
  • Number of Ports: 18
  • Max RJ45 Transfer Rate: 10/100/1000 Mbps
  • #Hide#Max SFP Transfer Rate: GB SFP
  • Interface(s): 16 x PoE+ gigabit RJ45 ports
    2 x gigabit non-PoE RJ45 ports
    2 x combo gigabit SFP slots
  • PoE Ports (RJ45): Standard: 802.3at/802.3af compliant
    PoE Ports: Ports 1–16
    PoE Power Budget: 250 W
  • Standards and Protocols: “IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at, IEEE 802.1q, IEEE 802.1p”
  • Switching Capacity: 36 Gbps
  • Power Supply: “100–240 VAC, 50/60 Hz

    Max Consumption:
    21.4 W (220/50 Hz. no PD connected)
    286.64 W (220/50 Hz. with 250 W PD connected)”

  • Dimensions: 440 x 180 x 44 mm
  • Mac Address Table: 8K
  • Packet Forwarding Rate: 26.78 Mbps
  • Jumbo Frame: 10 KB
  • Additional Features: See Overview
  • Quality of Service: 802.1p/DHCP QoS
  • Security: Physical security lock
  • Management: –
  • Environment: Operating Temperature: 0–50 °C (32–122 °F)
    Storage Temperature: -40–70 °C (-40–158 °F)
    Operating Humidity: 10–90% RH non-condensing
    Storage Humidity: 5–90% RH non-condensing
  • Package Contents: TL-SG1218MP
    Installation Guide
    Power Cord
    Rackmount Kit
    Rubber Feet
  • Package Type: Retail
  • Package Weight: 3.0700 kg
  • Warranty: Limited Lifetime
  • #Hide#POE: Yes

In stock

EAN: 6935364072162 SKU: TL-SG1218MP Category:

Description

18-Port Gigabit Rackmount Switch with 16 PoE+

  • 16x gigabit PoE+ RJ45 ports, 2x gigabit non-PoE RJ45 ports, and 2x combo gigabit SFP slots
  • High PoE power budget with up to 30 W for each PoE port and 250 W for all PoE ports*
  • Working with IEEE 802.3af/at compliant PDs
  • Plug and play, with no configuration and installation needed
  • 802.1p/DSCP QoS enable smooth latency-sensitive traffic
  • Durable metal casing and professional heat dissipation design ensure a wide operating temperature range (0–50C)





Dedicated 16-Port PoE+ Switch (250 W Budget) for Numerous Applications
Compliance with the 802.3af/at PoE+ standard supports up to 30 W on each PoE port. The total 250 W PoE power budget* for the 16x gigabit PoE+ ports makes it suitable for a wide range of applications, from surveillance to networking in offices, dormitories, and small businesses. It is fully compatible with IP cameras, access points, IP phones, computers, printers, and etc.

QoS for a Lag-Free Experience
Ensures smooth traffic for latency sensitive applications, such as voice and video, by designating the priority of traffic based on Quality of Service (QoS).

Intelligent Power Management to Prevent Power Overload
When your total power consumption exceeds 250 W, Intelligent Power Management automatically cuts lower priority ports’ power to ensure high-priority ports’ power supply. This protects the device from power overload operation. It also automatically detects the required PoE power for your device and protects your non-PoE equipment from being damaged.

Wide Operating Temperature with Good Heat Dissipation
Durable metal casing and professional heat dissipation design ensure the wide operating temperature (0–50C) with reliability.

Multiple Application Scenarios
The TL-SG1218MP is fully compatible with PoE devices, such as IP cameras, access points, and IP phones. It also works with non-PoE wired devices to provide gigabit connections, such as PCs, printers, and IPTV.

*PoE budget calculations are based on laboratory testing. Actual PoE power budget is not guaranteed and will vary as a result of client limitations and environmental factors.



Additional information

Weight 3.07 kg
Brand

TP-LINK
MPN

TL-SG1218MP
