TP-LINK (TL-SG2016P) JetStream 16-Port Gigabit Smart Switch with 8-Port PoE+, Centralized Management

TP-LINK (TL-SG2016P) JetStream 16-Port Gigabit Smart Switch with 8-Port PoE+, Centralized Management

£182.99

Description

Specification

  • Rackmountable: No
  • Managed: Smart
  • Number of Ports: 8
  • Max RJ45 Transfer Rate: 10/100/1000 Mbps
  • Interface(s): 8 x 10/100/1000 Mbps RJ45 Ports
    Auto-Negotiation/Auto MDI/MDIX
  • PoE Ports (RJ45): Standard: 802.3af/at compliant
    PoE Ports: 4 Ports
    Power Supply: 62 W
  • Bandwidth: 16 Gbps
  • Standards and Protocols: “IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.1x”
  • Power Supply: External Power Adapter (Output: 53.5 VDC/ 1.31 A)
  • Dimensions: 209 x 126 x 26 mm
  • Mac Address Table: 8k
  • Packet Forwarding Rate: 4.1 Mbit
  • Jumbo Frame: 9 KB
  • Quality of Service: 802.1p CoS/DSCP priority
    8 priority queues
    Priority Schedule Mode
    Queue Weight Config
    Bandwidth Control
    Smoother Performance
    Storm Control
  • Layer Features: Click here for Layer Features
  • VLAN: VLAN Group
    802.1Q tag VLAN
    MAC VLAN
    Protocol VLAN
    GVRP
    Voice VLAN
  • Access Control: Support up to 230 entries
    Time-Range
    Time-based ACL
    MAC ACL
    IP ACL
    IPv6 ACL
    Combined ACL
    Rule Operation
    Policy Action
    ACL Rules Binding
    Actions for flows
  • Security: AAA
    802.1X
    IP/IPv6-MAC Binding
    IP Source Guard
    IPv6 Source Guard
    DoS Defend
    Static/Dynamic/Permanent Port Security
    Broadcast/Multicast/Unicast Storm Control
    Port Isolation
    Secure web management through HTTPS with SSLv3/TLS 1.2
    Secure CLI management with SSHv1/SSHv2
    IP/Port/MAC-based access control
  • Management: “Omada App
    Centralized Management
    Cloud Access
    Web-based GUI
    CLI through telnet
    SNMPv1/v2c/v3
    SNMP Trap/Inform
    RMON (1,2,3,9 groups)
    SDM Template
    DHCP/BOOTP Client
    Dual Image, Dual Configuration
    CPU Monitoring
    Cable Diagnostics
    EEE
    SNTP
    System Log”
  • Environment: “Operating Temperature: 0–40 C (32–104 F);
    Storage Temperature: -40–70 C (-40–158 F)
    Operating Humidity: 10–90% RH non-condensing
    Storage Humidity: 5–90% RH non-condensing”
  • Package Contents: TL-SG2008P
    Power Adapter
    Installation Guide
    Rubber Feet
  • Package Type: Retail
  • Package Weight: 1.2000 kg
  • Warranty: Limited Lifetime
  • #Hide#POE: Yes

In stock

EAN: 4897098689349 SKU: SG2016P Category:

Description

JetStream 8-Port Gigabit Smart Switch with 4-Port PoE+

  • 62 W PoE Budget: 4x 802.3at/af-compliant PoE+ ports with a total power supply of 62 W*.
  • Full Gigabit Ports: 4x gigabit PoE+ ports and 4x gigabit non-PoE ports provide high-speed connections.
  • Integrated into Omada SDN: Zero-Touch Provisioning (ZTP)**, Centralized Cloud Management, and Intelligent Monitoring.
  • Centralized Management: Cloud access and Omada app for ultra convenience and easy management.
  • Robust Security Strategies: IP-MAC-Port Binding, ACL, Port Security, DoS Defend, Storm control, DHCP Snooping, 802.1X, Radius Authentication, and more.
  • Optimize Voice and Video Applications: L2/L3/L4 QoS and IGMP snooping.




Multiple Application Scenarios
The TL-SG2008P is fully compatible with PoE devices, such as IP cameras, access points, and IP phones. It also works with non-PoE wired devices to provide gigabit connections, such as PCs, printers, and IPTV.

Power over Ethernet for Simplified Network Deployment
Features four 802.3af/at compliant PoE+ ports, the switch supports up to 62 W total PoE power budget.* Designed to use a single Ethernet cable for both data and power transmission, it offers flexible deployment for PoE-supported devices such as wireless access points, IP cameras, and IP phones, lowering infrastructure costs for small businesses.

Access Control List (ACL)
ACL serves as a virtual admin, allowing all connected devices to obtain data in accordance with user-defined network rules and help you create the network regulations you need.





QoS for Lag-Free Experience
Designate the priority of traffic based on QoS, ensuring latency sensitive applications like voice and video, remain clear and lag-free.





VLAN for Security
Use VLAN to achieve logical grouping management of devices in different physical LANs, improve information security, and reduce data congestion.

Omada SDN – Smarter Cloud Solution for Business Networking
Omada Software Defined Networking (SDN) platform integrates network devices including access points, switches and gateways, guaranteeing powerful business network with higher efficiency, higher security, and higher reliability.

Hassle-Free Centralized Cloud Management:
100% centralized cloud management of whole network from different sites—all controlled from a single interface anywhere, anytime.

Easy Management with the Omada App
Follow configuration instructions on the free Omada app to get set up in minutes. Omada lets you configure settings, monitor the network status and manage clients, all from the convenience of a smart phone or tablet.



*PoE budget calculations are based on laboratory testing. Actual PoE power budget is not guaranteed and will vary as a result of client limitations and environmental factors.

**Zero-Touch Provisioning requires the use of Omada Cloud-Based Controller.

Additional information

Weight 2.3 kg
Brand

TP-LINK
MPN

SG2016P
