Cooler Master XG650 Platinum PSU – 80 Plus Platinum (+92% Efficiency) 650W, Fully Modular, Smart Thermal Control Mode, 135mm FDB ARGB Fan

Description

Silence Is Platinum
With a focus on thermal dissipation and maximized efficiency, this platform allows Cooler Master to offer an entirely new class of high efficiency products with 100% Japanese capacitors, boasting top-shelf performance with reduced ripple noise.

First In-house Design Platform
Cooler Master keeps searching for uniqueness, creativity, and more. XG Platinum is the first Cooler Master in-house designed power supply, providing next-level efficiency, rigid design, and sturdy performance to fulfill all your daily computing and gaming needs.

Crafted For Excellence
This professional grade power supply unit is built with full-bridge LLC resonant converter and DC-DC technology, made for the all users providing stability, reliability and so much more.

Silence is Platinum
XG650 Platinum offers smart thermal control mode which you can do more with your system in the minimal level of noise generated by the silent fan.

Fan Up, Fan Down
Both side panels on the XG Platinum are embossed with a stylish silk screen printed design. Install your PSU in either a fan up or fan down orientation while retaining 100% of the unit’s aesthetic value anytime, anywhere.

Build Your Way
Every facet of the XG Platinum was chosen with the goal of maximizing efficiency and thermal performance. Full modular cables were a must so that users could minimize the number of cables in their system based on their needs, reducing clutter and increasing both airflow and aesthetic quality.

Specifications

ATX Version
Intel ATX 12V Ver. 2.53

PFC
Active PFC

Input Voltage
100-240V

Input Current
8-4A

Input Frequency
50-60Hz

Dimensions
160 x 150 x 86 mm

Fan Size
135mm

Fan Speed
1800 RPM

Noise Level @ 100%
= 25 dBA

Efficiency
= 92% @ Typical Load

80 PLUS Rating
80 PLUS Platinum

ErP 2014 Lot 3
Yes

Operating Temperature
0-50?C

Power Good Signal
100 – 150 ms

Hold Up Time
= 20ms

MTBF
>100,000 Hours

Protections
OPP, OVP, OCP, UVP, SCP, OTP, Surge and Inrush Protection

Regulatory
TUV, cTUVus, CE, BSMI, FCC, CCC, EAC, UKCA

ATX 24 Pin Connectors
1

EPS 4+4 Pin Connectors
1

EPS 8 Pin Connector
1

SATA Connectors
8

Peripheral 4 Pin Connectors
4

PCI-e 6+2 Pin Connectors
4

Series
XG Series

80 Plus
Platinum

Modular
Full Modular

Wattage
650W
